MRS05 PCB Mount Reed Sensor with Resistor
Download 3D CAD (.STEP)Description
MRS05 PCB Mount Reed Sensor with Resistor
The MRS05 combines a reed switch with an integrated resistor in a PCB-mountable package. Designed for surface-mount or through-hole reflow assembly, it streamlines automated manufacturing while providing reliable magnetic sensing.
Product Specifications
| Parameter | Specification |
|---|---|
| Series | MRS05 |
| Type | PCB Mount Reed Sensor with Resistor |
| Rated Voltage | 200V DC |
| Rated Current | 0.5A |
| Package | PCB Mount, Resistor Integrated |
| Contact Form | 1A (SPST-NO) |
| Operating Temperature | -40°C to +125°C |
Key Features
- PCB mountable — compatible with automated assembly
- Integrated resistor reduces component count
- Reflow soldering compatible
- IP67 rated
- Stable contact resistance
- Multiple sensitivity grades
Applications
- Automated PCB assembly
- Consumer electronics
- Industrial control boards
- Automotive electronics
