High Voltage Reed Relay Family Overview (series)
SHR’s high voltage reed relay portfolio spans 200V open-frame types to 15KV high-insulation relays: HVR (4KV/6KV, 100W), HVFR (open-frame, up to 4KV), HVSR (8KV breakdown, 50W), HRX (up to 15KV, 1012 Ω insulation), plus multi-channel HRM relay modules. All values below are series-level ranges.
| Isolation / breakdown range (series) | 200 V – 15 KV across families |
| Contact rating range (series) | 10 W – 100 W across families |
| Insulation resistance (series) | Up to 1013 Ω |
| Compliance | RoHS |
HVR, HVFR, HVSR, HRX series and HRM high-voltage relay modules.
All values above are series-level specifications from the official SHR datasheet; individual model ratings may differ. Please refer to the series datasheet or submit an RFQ to confirm the exact configuration for your application.
Choose high-voltage reed relays by breakdown voltage, switching/carry current, contact form, coil voltage, insulation resistance, mounting style and high-voltage creepage constraints.
Use these models as starting points when comparing voltage, current, contact form, package and application duty.
