MRS04 Reed Switch with Integrated Resistor
Download 3D CAD (.STEP)Description
MRS04 Reed Switch with Integrated Resistor
The MRS04 integrates a pull-up or pull-down resistor directly into the reed sensor package, simplifying circuit design by eliminating the need for external components. Ideal for direct digital interface applications.
Product Specifications
| Parameter | Specification |
|---|---|
| Series | MRS04 |
| Type | Reed Sensor with Integrated Resistor |
| Rated Voltage | 200V DC |
| Rated Current | 0.5A |
| Package | Through-hole, Resistor Integrated |
| Contact Form | 1A (SPST-NO) |
| Operating Temperature | -40°C to +125°C |
Key Features
- Built-in pull-up/pull-down resistor
- Simplified circuit design — no external resistor needed
- Direct digital logic interface
- IP67 protection
- Multiple resistor value options
- Reduced BOM and PCB space
Applications
- Digital interface circuits
- PLC input modules
- Microcontroller-based systems
- Simplified sensor integration
Downloads
📄 Download MRS04 Datasheet (PDF)
