24V 2 Channel High Current Mercury 5A Wetted Relay HGSR24-2A04

Original price was: $158.53.Current price is: $138.21.

Product Feature High Power Mercury Reed Relay, Dielectric Strength up to 8000VDC
High Carry Current up to 100A(Pulse Carry Current)
Low Contact Resistance
Excellent Lifetime Characteristics
High Insulation Resistance up to 1010
Custom design avaiable for lay out

SKU: 1158808096162 Category: Tag:

Description

Mercury Wetted Relay HGSR24-2A04

Product Attributes

TYPE DESCRIPTION
Category Mercury Wetted Relays
Mfr SHR Reed Relay
Series 2 channels 4kv
Package Bulk
Mounting Type Through Hole
Coil Parameters
Coil Voltage 24 VDC
Coil Type Non Latching
Features Diode, Electrostatic Shield
Termination Style PC Pin
Must Operate Voltage 28 VDC
Must Release Voltage 2 VDC
Max Operating Voltage 29 VDC
Coil Resistance 2000 Ohms
Contact Parameters
Max Contact Rating 100W
Max Switch Voltage 500VAC Peak/VDC
Max Switch Current 2A
Max Carrying Current 5A
Min Breakdown Voltage 4K VDC
Max Contact Resistance 50 mohm
Relay Parameters
Operating Temperature -20°C ~ 70°C
Storage Temperature -35°C ~ 105°C
Min Breakdown Voltage 4K VDC
Dielectric Strength coil/contact 4K VDC
Operate Time 2 ms
Reset Time 2 ms
Capacitance Across Contacts 1.5pF
Soldering Temperature 5sec max 260℃



Additional information

Weight 1 kg
Dimensions 15 × 15 × 15 cm
