Description
MRS02 Molded Reed Sensor
The MRS02 is a compact molded reed sensor offering reliable magnetic proximity detection in a ruggedized package. Available in standard (MRS02), type A (MRS02A), and type B (MRS02B) variants for different mounting and sensitivity requirements.
Product Specifications
| Parameter | Specification |
|---|---|
| Series | MRS02 |
| Type | Molded Dry Reed Sensor |
| Rated Voltage | 200V DC |
| Rated Current | 0.5A |
| Package | Molded, Compact |
| Contact Form | 1A (SPST-NO) |
| Operating Temperature | -40°C to +125°C |
Key Features
- Multiple variants: Standard, Type A, Type B
- IP67 protection rating
- Hermetically sealed glass capsule
- No power required for sensing
- EMI resistant — no false triggering
- Long lifecycle: 10^9 operations
Applications
- Industrial automation — cylinder position sensing
- Security systems — access control
- Automotive — trunk, hood sensors
- Appliance — door open/close detection
Downloads
📄 Download MRS02 Datasheet (PDF)
← Back to Reed Sensor Overview | View All Product Models
