15KV Contact 24V Coil High Voltage Reed Relay HVR24-1A15-06

Name: 15KV Contact 24V Coil High Voltage Reed Relay HVR24-1A15-06
Brand: MiRelay
Price: 50.0 USD
Availability: InStock

Technical product information for engineering review. Request datasheet, samples, pricing, lead time, or a cross-reference recommendation for this part.

Request Quote Cross Reference

Sale!

15KV Contact 24V Coil High Voltage Reed Relay HVR24-1A15-06

Original price was: $60.00.Current price is: $50.00.

Product Features
Breakdown Voltage up to 15KVDC
Coil Voltage 24V
Low Contact Resistance
Excellent lifetime Characteristics
Hermetically sealed for long life
Low Contact resistance
Custom design available

Sample, Datasheet & Engineering Support

Model: HVR24-1A15-06
Purchase path: Buy sample online
Production projects: RFQ recommended for final electrical confirmation.

Download PDF Datasheet Request Production Quote Sample Store

Submit RFQ Form Email RFQ for This Part Cross Reference

For faster support, include voltage/current, contact form, coil voltage, quantity and application.

Model detail

HVR24-1A15-06 product details, applications and specifications

Select this family when the design needs compact high-voltage switching, low leakage, clean signal isolation and repeatable switching in test or instrumentation systems. The table below summarizes the key selection points; use the model datasheet for dimensions, ratings and ordering confirmation.

High Voltage Reed Relay principle illustration

1High-voltage input

2Hermetic reed switch

3Insulated relay package

4ATE / medical / HV output

Main specifications for RFQ

Public model: HVR24-1A15-06
Product family: High Voltage Reed Relays, 15KV Reed Relay
Coil Voltage: 24V
Breakdown Voltage: 15KVDC
Datasheet: Available as individual PDF for this model

Specifications above are extracted from the live product content for this model. Confirm final ratings, drawings and ordering code through the PDF datasheet or RFQ before production use.

Datasheet-style view

HVR24-1A15-06 technical data by section

Grouped specification blocks make this model page easier to scan for engineering selection, RFQ review and sample validation.

Electrical ratings

Breakdown / dielectric: 15KVDC
Voltage classes: 4kV / 6kV / 10kV / 15kV / 20kV series

Coil / control data

Coil voltage: 24V
Coil options: Model-specific coil voltage; confirm by datasheet/RFQ

Contact / output data

Contact forms: 1 Form A and series-dependent options

Mechanical & mounting

Insulation focus: High dielectric strength and low leakage signal switching
Mounting: PCB relay, module and custom high-voltage assembly options

Ordering / RFQ notes

Confirm exact ordering code, coil voltage, contact form and termination style before purchase.
Share load voltage/current, load type, duty cycle, ambient temperature and isolation requirement in RFQ.
Use the linked PDF datasheet for package drawing, dimensions and final rating limits.
For reed relays, keep switching voltage, stand-off/hold-off voltage and dielectric strength separate during selection.
Product family context: High Voltage Reed Relay.

Engineering selection notes

Avoid common specification mistakes

These notes keep product pages useful for engineers while avoiding overclaims. Final ratings remain model- and application-specific.

Separate switching, stand-off and dielectric ratingsSwitching voltage is the voltage the relay may open or close under specified load. Stand-off/hold-off and dielectric ratings are withstand tests and should not be treated as hot-switching capability.

Dry reed relays are low-bounce, not universally zero-bounceUse model datasheets for operate time and bounce behavior. Reserve bounce-free language for mercury wetted contacts or explicitly specified designs.

Load type controls lifeCapacitive inrush, inductive energy and hot-switching conditions can reduce contact life. Confirm load type, duty cycle and safety margin through datasheet review and RFQ.

Typical applications

Semiconductor ATE and wafer probe switching
Medical high-voltage diagnostic equipment
Cable / insulation / hipot test systems
Precision instrumentation and high-voltage multiplexing

What to confirm before purchase

Voltage, current, load type and safety margin
Contact form, coil voltage and drive circuit
Mounting, wiring, environmental and compliance requirements
Sample validation quantity and production forecast

FAQ

HVR24-1A15-06 ordering FAQ

These visible answers mirror the FAQ structured data and clarify what buyers should confirm before sample approval or production ordering.

What should be confirmed before ordering HVR24-1A15-06?

Confirm the exact ordering code, coil or control voltage, contact form or output type, voltage/current rating, mounting style, environmental conditions and validation quantity.

Is a PDF datasheet available for HVR24-1A15-06?

Yes. The model page links to an individual PDF datasheet for engineering review and RFQ confirmation.

What applications is this product family used for?

Semiconductor ATE and wafer probe switching, Medical high-voltage diagnostic equipment, Cable / insulation / hipot test systems, Precision instrumentation and high-voltage multiplexing.

Recommended next steps

HVR24-1A15-06 selection actions

Use these internal paths to move from overview to model comparison, datasheet review and RFQ submission.

Download model datasheetReview ratings, package drawing and ordering details Request engineering quoteSend load, voltage, quantity and validation requirements Compare all modelsBrowse the complete model index and related series View High Voltage Reed Relays familyReturn to category guide, comparison and representative models Family catalog PDFOpen the product-family catalog for broader selection Complete catalog PDFDownload the full public product catalog

Download HVR24-1A15-06 Datasheet Request quote for this model Compare all models

Model-level datasheet

HVR24-1A15-06 engineering datasheet

Download the original source PDF when available; if no source PDF exists, the checked MiRelay generated datasheet is used for ordering-code interpretation, key selection parameters, mechanical envelope guidance and RFQ checklist.

Download HVR24-1A15-06 PDF Request engineering RFQ

English engineering resources

Datasheet, catalog and RFQ support

Download the original source datasheet when available; otherwise use the checked generated English datasheet, family catalog, or RFQ path.

Download English Datasheet Family Catalog Complete Catalog Request Engineering Quote

Original source PDFs are preferred when available. Generated English PDFs are used only when no original source PDF is found; final ratings, drawings and application suitability are confirmed by RFQ.

Description
Additional information

Description

HVR24-1A15-06 high voltage reed relay

HVR24-1A15-06 is a 24V coil, 1 Form A, 15kV-class high voltage reed relay for engineering evaluation in test, measurement, medical, high-voltage instrumentation and switching systems.

Typical applications

Semiconductor ATE and wafer probe switching
Medical high-voltage diagnostic equipment
Cable, insulation and hipot test systems
Precision instrumentation and high-voltage multiplexing

Selection notes

Confirm switching voltage, carry current, load type and duty cycle before production use.
Keep switching rating, stand-off voltage and dielectric withstand rating separate during selection.
Share coil voltage, contact form, termination style, quantity and application details when requesting a quote.
Use the linked PDF datasheet and RFQ confirmation for final drawings, ratings and ordering code.

MiRelay is the high-voltage switching component brand operated by SHR AUTOSENSOR TECH LIMITED. For datasheet review, samples or production pricing, contact [email protected] or submit the RFQ form.

Request engineering RFQ

Download datasheet

Additional information

Weight	1 kg
Dimensions	15 × 15 × 15 cm

15KV Contact 24V Coil High Voltage Reed Relay HVR24-1A15-06
