High Voltage DC Contactors application and selection guide

High voltage DC contactors are designed for DC load control in battery, EV, charging, energy storage and industrial power systems where carry, make and break ratings must be matched to voltage, load type, polarity and pre-charge strategy.

Use this family for DC power-path control where arc suppression, contact life, coil control and thermal design must be confirmed against the real load profile.
